File Uploads with SonicJS and Cloudflare R2

Every CMS needs to handle files. Avatars, hero images, video clips, downloadable PDFs, podcast episodes — the moment your editors start using your platform, they expect upload to "just work." On most stacks, that's a multi-week project: provision S3, wire IAM, glue in a presigning service, write your own resizer, hope the egress bill stays sane.

On SonicJS, it's already built. This tutorial walks through the full media pipeline: configuring the R2 binding, posting your first upload, validating MIME types, serving public URLs, plugging in image transforms, and deleting cleanly. Every snippet maps to real code in @sonicjs-cms/core.

Why R2 for a Headless CMS

Cloudflare R2 is an S3-compatible object store — but with two characteristics that matter for an edge-first CMS:

1. Zero egress fees. Serving 1 TB of images from S3 costs about $90/month in bandwidth. From R2, it's $0. For a content-heavy site, that single line on the invoice is the entire ROI of moving to the edge.
2. Native Workers binding. Your Worker doesn't reach for an HTTP SDK and AWS-style signing. It calls c.env.MEDIA_BUCKET.put(...) directly. No DNS, no auth round-trip, no marshalling — same datacenter, microsecond reads and writes.

That's why SonicJS commits to R2 as the default storage layer. You can swap in any S3-compatible provider with a custom plugin, but the happy path is R2 and it stays that way.

Step 1: Configure the R2 Binding

The starter template already includes a bucket; you just need to create it and link the ID. Open wrangler.toml and confirm the binding looks like this:

# wrangler.toml
name = "my-cms"
main = "src/index.ts"
compatibility_date = "2024-01-01"
compatibility_flags = ["nodejs_compat"]

[[d1_databases]]
binding = "DB"
database_name = "my-cms-db"
database_id = "your-d1-id"

[[r2_buckets]]
binding = "MEDIA_BUCKET"
bucket_name = "my-cms-media"

[vars]
ENVIRONMENT = "development"
BUCKET_NAME = "my-cms-media"
# Optional — enables Cloudflare Images thumbnails
# IMAGES_ACCOUNT_ID = "your-account-hash"

The binding name must be MEDIA_BUCKET. SonicJS reads c.env.MEDIA_BUCKET directly in its upload handler, so anything else won't pick up your bucket. The BUCKET_NAME env var is used to build the default pub-{bucket}.r2.dev URL — set it to the same value as bucket_name.

Create the bucket with Wrangler:

# Create the R2 bucket
wrangler r2 bucket create my-cms-media

# (Optional) enable the public r2.dev URL for development
wrangler r2 bucket dev-url enable my-cms-media

That's the entire infrastructure setup. The media table is part of the core SonicJS schema, so once you run npm run db:migrate:local, you have a place to record every uploaded file.

Step 2: Add a Media Field to a Collection

SonicJS treats media references as a first-class field type. You don't store files inside your collection rows — you store a reference and let the media library own the bytes.

// src/collections/posts.ts
import { defineCollection } from '@sonicjs-cms/core'

export const postsCollection = defineCollection({
  name: 'posts',
  slug: 'posts',
  fields: {
    title: { type: 'string', required: true, maxLength: 200 },
    slug: { type: 'string', required: true, unique: true },
    body: { type: 'richtext' },

    // Single hero image
    heroImage: {
      type: 'media',
      title: 'Hero image',
      helpText: 'Recommended: 1792 × 1024 PNG or JPEG',
    },

    // A gallery of additional shots
    gallery: {
      type: 'array',
      items: { type: 'media' },
    },
  },
})

The media field stores the media record's ID. When you query a post via the content API, SonicJS resolves that ID into the full asset object — including publicUrl, mimeType, dimensions, and alt text — so frontends don't need to make a second round trip.

Step 3: Upload a File

Uploads are done through POST /api/media/upload with a standard multipart/form-data body. The endpoint requires authentication (see the authentication guide for how to issue tokens).

From the Command Line

curl -X POST https://my-cms.example.com/api/media/upload \
  -H "Authorization: Bearer $SONIC_TOKEN" \
  -F "file=@./hero.png" \
  -F "folder=blog-heroes"

The response includes everything you need to render the asset right away:

{
  "success": true,
  "file": {
    "id": "9f2c1b7d8e3a4f5b6c7d",
    "filename": "9f2c1b7d8e3a4f5b6c7d.png",
    "originalName": "hero.png",
    "mimeType": "image/png",
    "size": 412879,
    "width": 1792,
    "height": 1024,
    "r2_key": "blog-heroes/9f2c1b7d8e3a4f5b6c7d.png",
    "publicUrl": "https://pub-my-cms-media.r2.dev/blog-heroes/9f2c1b7d8e3a4f5b6c7d.png",
    "thumbnailUrl": null,
    "uploadedAt": "2026-05-13T18:42:09.000Z"
  }
}

A few things SonicJS does for you on the server, all visible in packages/core/src/routes/api-media.ts:

• Generates a 21-character ID to use as the filename (so original names never collide).
• Validates the MIME type against an explicit allowlist (no relying on user-supplied extensions).
• Calls c.env.MEDIA_BUCKET.put() with httpMetadata.contentType set so the file serves with the correct MIME on download.
• Stamps customMetadata with the uploader's userId and an ISO timestamp — useful for audit trails.
• Sniffs JPEG/PNG headers to pull width/height with no third-party dependency.
• Inserts a row into the media D1 table.

From a Browser with fetch

The same shape works straight from a frontend form:

async function uploadFile(file: File, folder = 'uploads') {
  const formData = new FormData()
  formData.append('file', file)
  formData.append('folder', folder)

  const res = await fetch('/api/media/upload', {
    method: 'POST',
    credentials: 'include', // sends the auth_token cookie
    body: formData,
  })

  if (!res.ok) {
    const err = await res.json()
    throw new Error(err.error ?? 'Upload failed')
  }

  return res.json()
}

// Wire it up to an <input type="file">
document.querySelector<HTMLInputElement>('#file')!
  .addEventListener('change', async (e) => {
    const input = e.target as HTMLInputElement
    if (!input.files?.[0]) return
    const result = await uploadFile(input.files[0], 'avatars')
    console.log('Uploaded:', result.file.publicUrl)
  })

If you need to upload several files at once, swap the endpoint for /api/media/upload-multiple and append every file to the same files field. The response splits successes from failures so a single bad file doesn't fail the whole batch.

Step 4: Validation — MIME Types and Size Limits

The validation rules live in a single Zod schema in api-media.ts. They cover three things:

// What the upload endpoint enforces
const fileValidationSchema = z.object({
  name: z.string().min(1).max(255),
  type: z.string().refine((type) => allowedTypes.includes(type), {
    message: 'Unsupported file type',
  }),
  size: z.number().min(1).max(50 * 1024 * 1024), // 50 MB
})

The default allowlist:

Category	MIME types
Images	image/jpeg, image/png, image/gif, image/webp, image/svg+xml
Documents	application/pdf, text/plain, application/msword, application/vnd.openxmlformats-officedocument.wordprocessingml.document
Video	video/mp4, video/webm, video/ogg, video/avi, video/mov
Audio	audio/mp3, audio/wav, audio/ogg, audio/m4a

Two important details:

1. The MIME type comes from the browser, which means the user can lie about it. SonicJS treats the MIME check as a first line of defense, not the last — never rely on it for security-critical decisions. For untrusted uploads, layer a server-side magic-byte sniffer or virus scanner via a plugin.
2. The 50 MB cap is the validator's number, but the practical limit on Cloudflare Workers is the request body size — currently 100 MB for paid plans and 10 MB on the free plan. If you need bigger uploads, use a presigned R2 URL flow and bypass the Worker entirely.

Step 5: Serving Files

Once a file is in R2, SonicJS gives you three ways to serve it.

A. The Default pub-*.r2.dev URL

The simplest option — the publicUrl you already got back from the upload response:

https://pub-my-cms-media.r2.dev/blog-heroes/9f2c1b7d8e3a4f5b6c7d.png

This works the moment you enable the dev URL on the bucket. It's perfect for development. For production, you almost certainly want option B or C.

B. A Custom Domain

In the Cloudflare dashboard, attach a custom domain (e.g. cdn.example.com) to your R2 bucket. After DNS propagates, every R2 object is reachable at https://cdn.example.com/<key>. Egress is free, the Cache-Control headers SonicJS sets are honored at the edge, and you control the URL surface.

C. The Built-In /files/* Proxy

SonicJS exposes a Worker-side route that streams from R2 with consistent headers, including Cache-Control: public, max-age=31536000 (one year) and permissive CORS:

GET https://my-cms.example.com/files/blog-heroes/9f2c1b7d8e3a4f5b6c7d.png

Use this when you want auth or transformation logic in front of an asset, or when you're keeping the R2 bucket private and don't want to expose it directly.

Public vs Private Buckets

By default a fresh R2 bucket is private — you have to explicitly enable the dev URL or attach a custom domain to expose objects. That's the right default for a CMS; nothing leaks until you decide it should. If you have user-only assets (think paid downloads or personal documents), keep the bucket private and serve through /files/* behind requireAuth() middleware. See the security guide for the full pattern.

Step 6: Image Transforms

Cloudflare offers two products for transforming images: Cloudflare Images (a managed pipeline with variants) and Image Resizing (URL-based on-the-fly transforms). SonicJS supports the first natively.

If you set the IMAGES_ACCOUNT_ID env var, every image upload also returns a thumbnailUrl pointing at Cloudflare Images:

// What the response looks like with Cloudflare Images enabled
{
  "thumbnailUrl": "https://imagedelivery.net/<account-hash>/<r2-key>/thumbnail"
}

You can swap thumbnail for any variant you've defined — public, hero, square, etc. — to get a different size from the same source bytes. Variants are configured in the Cloudflare dashboard, no code change required.

For URL-based transforms (cropping, format conversion, quality), prefix any /files/... URL with /cdn-cgi/image/<options> once Image Resizing is enabled on the zone:

https://cdn.example.com/cdn-cgi/image/width=800,quality=80,format=webp/blog-heroes/hero.png

Either approach keeps source files untouched and serves transformed bytes from the cache.

Step 7: Deleting Files

Two endpoints, both authenticated:

# Delete a single file
curl -X DELETE https://my-cms.example.com/api/media/9f2c1b7d8e3a4f5b6c7d \
  -H "Authorization: Bearer $SONIC_TOKEN"

# Bulk delete (max 50 IDs per call)
curl -X POST https://my-cms.example.com/api/media/bulk-delete \
  -H "Authorization: Bearer $SONIC_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"fileIds": ["9f2c1b...", "abc123..."]}'

Permissions are enforced server-side: only the original uploader or an admin role can delete a file. SonicJS performs a soft delete — the R2 object is removed and the media row gets a deleted_at timestamp. Existing references to the file ID still resolve in the database but stop returning a publicUrl, which lets you write a recovery flow before purging the row for good.

Putting It All Together: An Avatar Upload Component

Here's a minimal end-to-end avatar uploader using everything above — it validates the type client-side, posts to the API, and stores the returned ID on the user profile.

// avatar-uploader.ts
const ALLOWED = ['image/jpeg', 'image/png', 'image/webp']
const MAX_SIZE = 5 * 1024 * 1024 // 5 MB

export async function uploadAvatar(file: File) {
  if (!ALLOWED.includes(file.type)) {
    throw new Error('Only JPEG, PNG, or WebP, please.')
  }
  if (file.size > MAX_SIZE) {
    throw new Error('Avatar must be 5 MB or smaller.')
  }

  const formData = new FormData()
  formData.append('file', file)
  formData.append('folder', 'avatars')

  const upload = await fetch('/api/media/upload', {
    method: 'POST',
    credentials: 'include',
    body: formData,
  }).then((r) => r.json())

  if (!upload.success) {
    throw new Error(upload.error ?? 'Upload failed')
  }

  // Save the media reference on the current user's profile
  await fetch('/api/content/users/me', {
    method: 'PATCH',
    credentials: 'include',
    headers: { 'Content-Type': 'application/json' },
    body: JSON.stringify({ avatar: upload.file.id }),
  })

  return upload.file.publicUrl
}

Two HTTP calls, three layers of validation, one row in D1, one object in R2 — and it scales globally on the same Worker that serves the rest of your CMS.

Production Hardening Checklist

Before pointing real traffic at this:

• Lock down CORS — CORS_ORIGINS in wrangler.toml should list your frontend origins explicitly. Never * for an authenticated endpoint.
• Tighten the MIME allowlist — if your app only needs images, fork the validation schema in your project and remove video/audio types entirely.
• Drop the size cap — for an avatar app, 50 MB is overkill; bring it down to 5 MB or less to limit abuse.
• Rate-limit /api/media/upload — apply the built-in rateLimit() middleware so a single user can't burn through your R2 quota.
• Use a custom domain for assets — pub-*.r2.dev is fine for development but slow to revoke if a bucket leaks. A custom domain on a Cloudflare zone gives you per-route firewall rules.
• Audit deletes — enable the security audit plugin to log who deleted what and when.

Next Steps

You now have the full upload pipeline: a configured R2 binding, a media field on your collections, authenticated multipart uploads, validated MIME types, public asset URLs, optional Cloudflare Images variants, and clean deletes. Where to go next:

• Field types reference — every option for the media field, including arrays, conditional display, and reference pickers
• API reference — the complete endpoint surface for /api/media/*
• Security overview — CSRF, CORS, rate limiting, and signed URL patterns for private assets
• Authentication guide — how to issue and refresh the tokens uploads require
• Building a blog with SonicJS — see the media field used end-to-end in a real project

Key Takeaways

• The R2 binding is named MEDIA_BUCKET — SonicJS reads c.env.MEDIA_BUCKET directly, so the binding name must match exactly.
• Uploads are plain multipart/form-data posts to /api/media/upload — no SDKs, no presigning, no AWS auth headers.
• The default validator caps files at 50 MB and accepts an explicit allowlist of about 20 MIME types covering images, video, audio, and documents.
• Files are served via the public pub-*.r2.dev URL, a custom domain, or the Worker-side /files/* proxy with one-year caching.
• Setting IMAGES_ACCOUNT_ID automatically wires Cloudflare Images variants into every image upload.
• Deletes are soft by default — R2 objects go immediately, but the D1 row is tombstoned with deleted_at.

Have questions or want to share what you're building? Join us on Discord or GitHub.

Happy uploading!
